|Industry Standards||21 CFR Part 11, ISO 14644-1:2015, CE, FCC|
|Particle Size Analysis Range||0.5 - 5 μm|
|Coincidence Loss||10% at 4,000,000 particles/ft³|
|Sample Volume||5 µm|
|Throughput||2.83 L per minute|
|Interfaces & Protocols||USB Host (v1.1), USB Client (v1.1)|
|Data Storage||10,000 records|
|Battery||Lithium Ion (rechargeable) battery|
|Battery Operating Time||10+ hours (typical use) / minimum 5.5 hours (continuous sampling)|
|Battery Recharge Time||3.5 hours|
|Pump Accuracy||±5% Flow Rate|
|Pump Repeatability||±5% Flow Rate|
|Zero Count||Conforms to JIS B9921 (1 count or less in 5 min; 95% UCL)|
|Counting Efficiency||50% at 0.5 µm (100% for particles > 0.75 µm)|
|Count Alarms, Display & Cycles||Raw counts: N/CF, N/CM, N/L in cumulative or differential mode, User-defined alarm counts|
|Label Locations||Alphanμmeric Location Names|
|Environmental Conditions||Indoor Environment|
|Temperature Range||Operating temperature range: 10°C to 40°C, Storage temperature range: -10°C to 50°C|
|Humidity Restrictions||< 95% non-condensing|
|Power Requirements||100-240 VAC, 50/60 Hz, 1.0 A|
|Operating System||Windows IE, Safari and Firefox|
|Resolution||320 x 240|
|Display||3.5" high-resolution (320 x 240) color display|
|Operating Modes||Semi-automated, manual, controlled by operator|
|Weight||0.7 kg(1.5 lb)|
|Width||27 cm(10.6 in)|
|Depth||10 cm(3.9 in)|
|Height||5.3 cm(2.1 in)|
